Technical Data
Full specification
Every published figure for the Goldman range, with the test method it was measured under.
| Item | Specification | Test method |
|---|---|---|
| Gloss (60°) | ≥ 92% | GB 8807 |
| Finished weight | 405–425 g/m² | GB/T 4669 |
| Glue weight | 25–30 g/m² | GB/T 4669 |
| Product thickness | 210 ± 15 µm Per tier TBC | GB/T 7125 |
| Base film thickness | 180 ± 5 µm Per tier TBC | GB/T 7125 |
| Tensile strength | ≥ 380 kg/cm² | GB/T 10041 |
| Peel strength | ≥ 75 N/cm | GB/T 10041 |
| Elongation at break | ≥ 350% | GB/T 1040.1 |
| Shrinkage (MD) | ≤ 0.5 mm | FTM 14 |
| Shrinkage (TD) | ≤ 0.4 mm | FTM 14 |
| Release force | ≤ 0.35 N/25 mm | GB/T 2792 |
| Tack | ≥ 9 N/25 mm | FTM 9 |
| 24 h, 180° peel | ≥ 18 N/25 mm | GB/T 2792 |
| Maximum temperature | 120 °C ± 5 min | GB/T 2423.1 |
| Self-healing | Heat 75 °C, 0.1 mm | Brush & heat |
| Water contact angle | ≥ 103° | DL/T 864 |
| Anti-acid | Oxalate 72 h — pass | Lab test |
| Yellowness index | ≤ 2 | QUV |
| Anti-fouling | Strong marker — pass | Lab test |
These figures are for the PCF-180 platform. The two thickness rows are the ones
expected to differ between tiers, and per-tier values are published as each
technical data sheet is released rather than estimated in the meantime.
Appearance
Inspection criteria
Liner bubbles, dust, coated bumps and glue lines: visually invisible. Crystal points between 0.1 and 0.6 mm are permitted. Between 0.7 and 2.9 mm, fewer than ten. At 3.0 mm and above, a maximum of one. Protective film is removed before visual inspection.
Documents
Specification sheets
Product documentation for professional evaluation.
Technical reference
Reference test data for the PCF-series base film, per SGS report SUZMR260200089701 dated 03 March 2026, issued to the film manufacturer.
- Gloss 95.8 GU at 60° (BS EN ISO 2813:2014)
- Coating adhesion 5B, 5B, 5B (ASTM D3359-23)
- Tensile strength 35.4 MPa, elongation 410% (ASTM D638-22)
- No visible change after 24 hours in 5% sulfuric acid (ISO 2812-1:2017)
- No visible change after 384 hours at 80 °C
- Neutral salt spray 24 hours, pass (ISO 9227:2022+A1:2024)
- ΔE*ab 0.33 / 0.40 / 0.21 after 2000 hours UV ageing (ASTM G154-23 Cycle 1)
